Abanoub AbdelMessieh

{
  description = "FreeRTOS MQTT Sandbox & NUCLEO-C5A3ZG Build Environment";

  inputs = {
    nixpkgs.url = "github:NixOS/nixpkgs/nixos-unstable";
    flake-utils.url = "github:numtide/flake-utils";
  };

  outputs = { self, nixpkgs, flake-utils }:
    flake-utils.lib.eachDefaultSystem (system:
      let
        pkgs = import nixpkgs { inherit system; };
      in
      {
        devShells.default = pkgs.mkShell {
          buildInputs = with pkgs; [
            # Build Tools
            gnumake
            cmake
            ninja

            # Cross-Compilation Toolchain
            gcc-arm-embedded

            # Debugging & Flashing
            openocd
            gdb

            # Host Emulation & Broker
            qemu
            mosquitto

            # Scripting
            python3
            python3Packages.pip
            python3Packages.virtualenv

            # Host Libraries for Cortex-A7 Linux Device Agent Proxy
            openssl
            paho-mqtt-c
            pkg-config
          ];

          shellHook = ''
            echo "========================================================"
            echo "🚀 Nix Environment Active: FreeRTOS Sandbox"
            echo "   Toolchain: $(arm-none-eabi-gcc --version | head -n1)"
            echo "   CMake    : $(cmake --version | head -n1)"
            echo "========================================================"
          '';
        };
      }
    );
}

/*
 * FreeRTOS Kernel V11.2.0
 * Copyright (C) 2021 Amazon.com, Inc. or its affiliates. All Rights Reserved.
 *
 * SPDX-License-Identifier: MIT
 *
 * Permission is hereby granted, free of charge, to any person obtaining a copy of
 * this software and associated documentation files (the "Software"), to deal in
 * the Software without restriction, including without limitation the rights to
 * use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of
 * the Software, and to permit persons to whom the Software is furnished to do so,
 * subject to the following conditions:
 *
 * The above copyright notice and this permission notice shall be included in all
 * copies or substantial portions of the Software.
 *
 * THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
 * IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS
 * FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR
 * COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER
 * IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN
 * CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
 *
 * https://www.FreeRTOS.org
 * https://github.com/FreeRTOS
 *
 */

#ifndef INC_TIMELINE_SCHEDULER_H
#define INC_TIMELINE_SCHEDULER_H

#ifndef INC_FREERTOS_H
    #error "include FreeRTOS.h must appear in source files before include timelinescheduler.h"
#endif

/**
 * @brief Defines the classification of tasks within the timeline scheduler.
 *
 * The scheduler distinguishes between tasks that require strict deterministic
 * timing guarantees (Hard Real-Time) and those that run on a best-effort basis
 * during idle periods (Soft Real-Time).
 */
typedef enum
{
    /* Tasks that must execute within a specific subframe window and strictly
     * adhere to start and end times. */
    TASK_HARD_RT = 0,

    /* Tasks that execute in the remaining time of a subframe after Hard Real-Time
     * tasks have completed. They are scheduled in a fixed order. */
    TASK_SOFT_RT = 1
} TaskType_t;

/**
 * @brief Configuration structure for a single task in the timeline.
 *
 * This structure defines all properties required by the scheduler to manage
 * the task's execution, including its timing constraints, stack requirements,
 * and category.
 */
typedef struct
{
    /* A descriptive name for the task. This is used primarily for debugging
     * and identification purposes. */
    const char * pcTaskName;

    /* Pointer to the function that implements the task. The task function must
     * follow the standard FreeRTOS task signature: void vTaskCode( void * pvParameters ); */
    TaskFunction_t pxTaskCode;

    /* The category of the task (Hard Real-Time or Soft Real-Time). */
    TaskType_t xType;

    /* For Hard Real-Time tasks: The offset in ticks from the start of the
     * assigned subframe at which the task must begin execution.
     * For Soft Real-Time tasks: This field is ignored. */
    TickType_t xStartTime;

    /* For Hard Real-Time tasks: The deadline in ticks relative to the start
     * of the assigned subframe. The task must complete execution before this time.
     * For Soft Real-Time tasks: This field is ignored. */
    TickType_t xEndTime;

    /* The index of the subframe (0 to configTIMELINE_SUBFRAMES_PER_CYCLE - 1) in which this task is
     * scheduled to run. This is only relevant for Hard Real-Time tasks. */
    uint32_t ulSubframeId;

    /* The number of words (not bytes) to allocate for the task's stack. For example,
     * if the stack is 32-bits wide, a value of 100 allocates 400 bytes. */
    uint16_t usStackDepth;
} TimelineTaskConfig_t;

/**
 * @brief Initializes the timeline scheduler with the provided task configuration.
 *
 * This function parses the configuration array, creates the necessary internal
 * structures, and prepares the tasks for execution. It must be called before
 * the FreeRTOS scheduler is started via vTaskStartScheduler().
 *
 * @note The global configuration parameters configTIMELINE_TASK_COUNT, configTIMELINE_MAJOR_FRAME_TICKS, and configTIMELINE_MINOR_FRAME_TICKS
 *       must be defined in FreeRTOSConfig.h.
 *
 * @param[in] cfg Pointer to an array of TimelineTaskConfig_t structures. The array
 *                must contain exactly configTIMELINE_TASK_COUNT entries, defining the complete
 *                schedule for the system.
 */
void vConfigureScheduler( const TimelineTaskConfig_t * cfg );

/**
 * @brief Forcefully terminates a task and reschedules it for the next major frame.
 *
 * This function is designed to be called from timeline hooks (which run in
 * interrupt context) to enforce conditional dependencies or handle faults.
 *
 * @param[in] xTask The handle of the task to terminate.
 */
#if ( INCLUDE_vTaskTimelineTerminate == 1 )
    void vTaskTimelineTerminateFromISR( TaskHandle_t xTask );
#endif

#endif /* INC_TIMELINE_SCHEDULER_H */
